Outdoor Jacuzzi SPA — 5-person (1 lounge & 4 seats)
2300 × 2300 × 880 mm
Robust family spa in US Aristech acrylic with Balboa BP6013G2 + Touch3 control (3 kW heater). Powered by a quiet 0.5 HP circulation pump and dual 4 HP jet pumps driving a 91-jet hydrotherapy system.
Configuration / Power
- Control system
- Balboa BP6013G2 + Touch3 + 3 kW heater
- Power supply
- 220V / 380V / 110V
- Underwater lighting
- 1 pc
- Seating layout
- 1 lounge & 4 seats
Dimensions & Weight
- Product size
- 2300 × 2300 × 880 mm
- Dry weight
- 410 kg
- Filled weight
- 2210 kg
Shell & Cabinet
- Shell material
- US Aristech Acrylic
- Shell colors
- 7 options
- Shell insulation
- 2 cm
- Support frame
- Timber
- Base
- ABS
- Skirt
- PS skirt + PC corner
Pumps
- Circulation pump
- 1 × 0.5 HP
- Jet pumps
- 2 × 4 HP
Jet Configuration
- Total jets
- 91 pcs
- Jets 5″
- 1 pc
- Jets 3.5″
- 1 pc
- Jets 2″
- 89 pcs
Filtration & Hygiene
- Filter
- 1 × 50 sf
- Ozonator
- 1 pc
Equipment
- Suction
- 5 pcs
- Air valves
- 3 pcs
- Drainage outlet
- 1 pc
- Headrest pillows
- 3 pcs
Powerful & efficient
Dual 4-HP pumps and a dense jet array deliver strong, even massage; a timber/ABS cabinet and 2 cm insulation keep heat in and running costs stable.
Specs based on the manufacturer’s sheet — minor variations may occur depending on configuration.
