Outdoor Jacuzzi SPA — 5-person (5 seats)
1900 × 1900 × 1010 mm
Compact square spa in US Aristech Acrylic with Balboa BP200 G2 + TP500S controller and 3 kW heater. One-speed 3 HP jet pump and a 0.5 HP circulation pump power a focused 21-jet hydrotherapy layout.
Configuration / Power
- Control system
- Balboa BP200 G2 + TP500S + 3 kW heater
- Power supply
- 220V / 380V / 110V
- Underwater lighting
- 1 pc
- Seating layout
- 5 seats
Dimensions & Weight
- Product size
- 1900 × 1900 × 1010 mm
- Dry weight
- 335 kg
- Filled weight
- 1735 kg
Shell & Cabinet
- Shell material
- US Aristech Acrylic
- Shell colors
- 7 options
- Shell insulation
- 2 cm
- Support frame
- Solid timber frame
- Base
- ABS
- Skirt
- PS (optional colors)
Pumps
- Jet pump
- 1 × 3 HP (one-speed)
- Circulation pump
- 1 × 0.5 HP
Jet Configuration
- Total jets
- 21 pcs
- Hydrotherapy jets 3.5″
- 3 pcs
- Hydrotherapy jets 2.5″
- 13 pcs
- Hydrotherapy jets 1″
- 2 pcs
- Hydrotherapy jets 5″
- 1 pc
- Hydrotherapy jets 4″
- 2 pcs
Filtration & Hygiene
- Top-mount filter
- 1 pc; 1 × 50 sf (floating filter)
- Ozonator
- 1 pc
Equipment
- Suction
- 3 pcs
- Drainage outlet
- 1 pc
Specifications based on the manufacturer’s sheet — minor variations may occur depending on configuration.
