DJI Dock 3
The first docking station designed for vehicle mounting.
Full control in all conditions
The DJI Dock 3 is a rugged and reliable IP56-rated device that can withstand evenextreme wind conditions up to 12/ms, temperatures from -30°C to 50°C, providing unparalleled performance and reliability in any environment.
Easy deployment, stable data transmission
The DJI Dock 3 revolutionises drone operations by offering instant deployability, including vehicle mounting, advanced D-RTK 3 Relay technology for better quality ofsignal quality and easy smartphone configuration, resulting in unparalleled efficiency for long-range missions and inspections.
Fixed installation of the D-RTK3 module
The new D-RTK 3 Relay Fixed Deployment, revolutionises video transmission and satellite positioning, enabling flexible deployment of the DJI Dock 3 providing unparalleled performance over distances of up to 25km in challenging terrain.
The new DJI Matrice 4D series drone line-up
Discover the revolutionary DJI Matrice 4D and 4TD drones, developed specifically for DJI Dock 3, offering unparalleled performance, advanced camera systems and versatile applications from precision mapping to critical public safety missions.
LiDAR obstacle detection
The optional obstacle detection module, combines LiDAR technology with electromagnetic waves ranging from 1 to 10mm, providing precise avoidance of small obstaclesd such as high-voltage cables at speeds of up to 15 m/s, ensuring operational safety in complex environments such as power grid and substation inspections.
Transparency and precision for any task and at any time
The revolutionary Matrice 4D Series drones offer groundbreaking precision positioning and observation capabilities in low-light conditions, providing unparalleled operational capabilities at any time of day or night.
Stable imaging over long distances
Equipped with advanced telephoto cameras with foreground stabilisation, Matrice 4D Series drones revolutionise long-range inspection, enabling precise defect detection and data readout with unprecedented quality.
Precision surveying
Matrice 4D Series drones offering advanced oblique photography and orthophotography features, along with intelligent flight path planning, providing unparalleled efficiency and detail in terrain modelling.
Seamless connectivity in mountainous terrain
Equipped with DJI Relay's advanced relay technology, the innovative Matrice 4D drone series significantly extends range and operational capabilities, enabling seamless search and rescue and inspection missions even in complex terrain.
| GENERAL | |
|---|---|
| Model | DJI Dock 3 |
| Total weight | 55 kg (without drone) |
| Dimensions | Open cover: 1760×745×485 mm (L × W × H). Closed lid: 640×745×770 mm (L × W × H) |
| Input voltage | 100-240 V (AC), 50/60 Hz |
| Input power | Max 800 W |
| Operating temperature | -30° to 50° C |
| Degree of protection | IP56 |
| Number of drones that can be accommodated | 1 |
| Maximum permissible wind speed on landing | 12 m/s |
| Maximum operating altitude | 4500 m |
| RTK base station frequency | Simultaneous reception: GPS: L1 C/A, L2, L5 BeiDou: B1l, B2l, B3l, B2a, B2b, B1C GLONASS: F1, F2 Galileo: E1, E5a, E5b, E6 QZSS: L1, L2, L5 |
| RTK base station positioning accuracy | Horizontal: 1 cm + 1 ppm (RMS) Vertical: 2 cm + 1 ppm (RMS) |
| CHARGING PARAMETERS | |
| Output voltage | 35 V DC |
| Charging time | 27 minutes |
| VIDEO TRANSMISSION | |
| Operating frequency | 2.400-2.4835 GHz 5.150-5.250 GHz (CE: 5.170-5.250 GHz) 5.725-5.850 GHz |
| Antenna | 9 antennas built-in, 2T4R, supports smart switching |
| Transmitter power (EIRP) | 2.4 GHz: < 33 dBm (FCC), < 20 dBm (CE/SRRC/MIC) 5.2 GHz (CE: 5.170-5.250 GHz): < 23 dBm (FCC/CE) 5.8 GHz: < 33 dBm (FCC); < 14 dBm (CE); < 30 dBm (SRRC) |
| COOLING SYSTEM | |
| Operating voltage | 48 V DC |
| Type | Cooling system with compressor |
| EMERGENCY BATTERY | |
| Capacity | 12 Ah |
| Output voltage | 12 V |
| Cell type | Lead-acid battery |
| Operating time | 4 h |
| ACCESS TO MAINS | |
| Ethernet | Adaptive Ethernet port 10/100/1000 Mbps |
| 4G | DJI Cellular Dongle 2 dongle required |
| SENSORS | |
| Wind speed sensor | Yes |
| Rain sensor | Yes |
| Ambient temperature sensor | Yes |
| Water immersion sensor | Yes |
| Housing temperature sensor | Yes |
| Humidity sensor in housing | Yes |
| SECURITY CAMERA (EXTERNAL) | |
| Resolution | 1920x1080 |
| Field of view (FOV) | 151° |
| Auxiliary light | White |
| SECURITY CAMERA (INTERNAL) | |
| Resolution | 1920x1080 |
| Field of view (FOV) | 151° |
| Auxiliary light | White |
| LIGHTNING PROTECTION | |
| AC input port | 20 kA (rated value), complies with EN 61643-11 Type 2 and IEC 61643-1 Class Ⅱ protection level |
| Ethernet port | 10 kA (total), complies with EN/IEC 61643-21 for protection level Category C |
| SUPPORTED SOFTWARE | |
| Applications | DJI Enterprise app (used with Android phones for deployment and commissioning) |
| Cloud Platform | FlightHub 2 FlightHub 2 On-Premises Version FlightHub 2 FlightHub Sync DJI Cloud API |
| EXPANSION POSSIBILITIES | |
| Edge Computing Technology | Supports data communication with external network switches |
