Autonomous missions on a whole new level
The DJI Dock 2 is a high-performance unmanned platform equipped with the innovative Matrice 3D or Matrice 3TD drone.
Ultralight design
Compared to the previous generation, the dimensions and weight of the DJI Dock 2 have been reduced by 75% and 68% respectively significantly improving the freedom of installation.
Quick terrain analysis
Prior to deployment, the drone can identify its surroundings using vision sensors and quickly determine whether the deployment area has good GNSS signals. Compared to the previous system, the new survey system significantly speeds up site selection, with the required time reduced from around five hours to 12 minutes.
Reliable operation, safety and readiness
The DJI Dock 2 is not only lightweight and easy to deploy, but also has enhanced operational capabilities. With intelligent cloud-based features, it significantly simplifies unattended missions, achieving a whole new level of quality and operational efficiency.
IP55 protection rating
The DJI Dock 2 uses a high-protection design, and the dust and water resistance of the entire unit reaches IP55 [1]. The device can operate stably for a long time even in harsh climatic and environmental conditions.
Environmental conditions monitoring system
The DJI Dock 2 integrates sensors such as a rain sensor, anemometer and thermometer that can detect changes in the weather in real time. Combined with online weather forecasts, Dock 2 can provide timely warnings or suspend scheduled flight missions, effectively reducing sub-mission risk.
More stable landings
Thanks to a new generation of image recognition technology, the drone can more accurately identify landing marks over the platform. What's more, the landing pad has been designed to further improve landing efficiency.
Built-in emergency battery
In the event of an unexpected power failure, the Dock 2 can continue to operate independently for more than 5 hours using the built-in battery.
Inspection every 6 months
Thanks to its high-protection design and high reliability, the Dock 2 only requires maintenance once every 6 months.
Exceptional event warnings
When a malfunction or emergency occurs on the DJI Dock 2 or your drone, the Dock 2 will send an email as soon as possible.
Kit contents:
- 1x DJI Dock 2
- 1x Anemometer
- 4x Anchor
- 1x Ethernet cable connector
- 1x Power cable connector
- 1x Screwdriver
| DOCKING STATION - GENERAL INFORMATION | |
|---|---|
| Total weight | 34 kg (without drone) Actual product weight may vary due to differences in materials and external factors. |
| Dimensions | Open dock lid: 1228×583×412 mm (L × W × H). Dock lid closed: 570×583×465 mm (L × W × H). The above figures do not include the height of the wind speed meter (145 mm ), but take into account the height of the mounting base brackets (55 mm). |
| Input voltage | 100-240 V (AC), 50/60 Hz |
| Input power | Max 1000 W |
| Operating temperature | -25° to 45° C (-13° to 113° F) When the ambient temperature is below -20° C (-4° F), the docking station is in standby mode and the drone cannot perform flight tasks. |
| Degree of protection | IP55 |
| Maximum number of drones | 1 |
| Maximum permissible wind speed on landing | 8 m/s |
| Maximum operating altitude | 4000 m |
| RTK base station frequency | Simultaneous reception: GPS: L1 C/A, L2 BeiDou2: B1l, B2l, B3l BeiDou3: B1l, B3l GLONASS: L1, L2 Galileo: E1, E5B |
| RTK base station positioning accuracy | Horizontal: 1 cm + 1 ppm (RMS) Vertical: 2 cm + 1 ppm (RMS) |
| DOCKING STATION - CHARGING CAPACITY | |
| Output voltage | 28 V DC |
| Charging time | 32 minutes Data was measured while charging the drone (with power off) from 20% to 90% at 25°C (77°F). |
| DOCKING STATION - VIDEO TRANSMISSION | |
| Video transmission system | O3 Enterprise |
| Operating frequency | 2.4000-2.4835 GHz 5.725-5.850 GHz |
| Transmitter power (EIRP) | 2.4 GHz: < 33 dBm (FCC); < 20 dBm (CE/SRRC/MIC) 5.8 GHz: < 33 dBm (FCC); < 14 dBm (CE); < 23 dBm (SRRC) |
| DOCKING STATION - COOLING SYSTEM | |
| Operating voltage | 28 V DC |
| Cooling system type | TEC air-conditioning |
| DOCKING STATION - EMERGENCY BATTERY | |
| Battery capacity | 12 Ah |
| Output voltage | 12 V |
| Battery type | Lead-acid battery |
| Emergency battery operating time | > 5 hours Measured with fully charged backup battery at 25° C (77° F). After a power outage, the docking station does not support functions such as charging the drone, air conditioning, dock lid heating and wind speed indicator heating. Always check outages immediately. |
| DOCKING STATION - MAINS ACCESS | |
| Ethernet network access | Adaptive 10/100/1000Mbps Ethernet port |
| DOCKING STATION - SENSORS | |
| Wind speed sensor | Supported |
| Precipitation sensor | Supported |
| Ambient temperature sensor | Supported |
| Water immersion sensor | Supported |
| In-Cabin Temperature Sensor | Supported |
| Cab humidity sensor | Supported |
| DOCKING STATION - SECURITY CAMERA (EXTERNAL) | |
| Resolution | 1920×1080 |
| Field of view (FOV) | 151° |
| Auxiliary light | Auxiliary white light |
| DOCKING STATION - SECURITY CAMERA (INTERNAL) | |
| Resolution | 1920×1080 |
| Field of view (FOV) | 151° |
| Auxiliary light | Auxiliary white light |
| DOCKING STATION - LIGHTNING PROTECTION | |
| AC supply port | 20 kA (rated value), complies with protection level EN 61643-11 type 2 and IEC 61643-1 class Ⅱ. |
| Ethernet port | 10 kA (total), meets protection level EN/IEC 61643-21 category C |
| DOCKING STATION - SUPPORTED SOFTWARE | |
| Applications | DJI Pilot 2 (connects to DJI Dock 2 via DJI RC Pro Enterprise camera for installation and commissioning) |
| Cloud platform | DJI FlightHub 2 (supported by default) Third-party cloud platforms (access via DJI Cloud API) |
| DOCKING STATION - EXPANDABLE | |
| Open protocol | DJI Cloud API |
| Edge Computing | Supports data communication with external switches |
