Outdoor Jacuzzi SPA L502 — 5-person (2 lounges & 3 seats)
L502
L502 is a compact 5-person spa built with US Aristech acrylic, powered by Balboa BP6013 G3 + TOUCH3 electronics and a 3 kW heater. A well-balanced jet mix, quiet circulation and ergonomic seating deliver daily wellness at home.
Overview
Two comfortable lounges and three contoured seats provide full-body relaxation. Mixed jet sizes (1″ to 5″), 2 cm shell insulation and robust materials make L502 both powerful and efficient.
- 84 total jets — targeted massage for back, shoulders and calves.
- Balboa control — stable temperature, intuitive touch panel.
- Durable build — Aristech acrylic, ABS base, 10 mm aluminium skirt + ABS corners.
Configuration / Power
- Control system
- Balboa BP6013 G3 + TOUCH3 + 3 kW heater
- Power supply
- 220V / 380V / 110V
- Underwater lighting
- 1 pc
- Seating layout
- 2 lounges & 3 seats
Dimensions & Weight
- Product size
- 2200 × 2200 × 880 mm
- Dry weight
- 380 kg
- Filled weight
- 1960 kg
Materials
- Shell material
- US Aristech Acrylic
- Shell colors
- 7 options
- Shell insulation
- 2 cm
- Support frame
- Timber
- Base
- ABS
- Skirt
- Aluminium panel (10 mm) + ABS corners
Pumps
- Circulation pump
- 1 × 0.5 HP
- Jet pumps
- 3 × 3 HP
Jet Configuration
- Total jets
- 84 pcs
- Jets 5″
- 4 pcs
- Jets 3.5″
- 11 pcs
- Jets 3″
- 23 pcs
- Hydrotherapy jets 2.5″
- 24 pcs
- Jets 1″
- 22 pcs
Filtration & Hygiene
- Filter
- 2 × 50 sf (top-mount)
- Ozone generator
- 1 pc
Equipment
- Suction
- 6 pcs
- Air valves
- 3 pcs
- Drainage outlet
- 1 pc
- Headrest pillows
- 3 pcs
Comfort & longevity
The 220 × 220 cm footprint fits five seats comfortably. Aluminium panels with ABS corners add durability, while the 2 cm shell insulation helps retain heat longer.
Specs based on the manufacturer’s sheet — minor variations may occur depending on configuration.
